MA30M ACE Controls Miniature Shock Absorbers
$0.00
| Stroke | 0.32 inch |
| M | M8x1 inch |
Miniature Shock Absorbers
MA30M
Stepless adjustment
Adjustable
Energy capacity 31 in-lbs/cycle
Stroke 0.32 inch
There are also plenty of accessories for the MA and MVC models. All products are ready-to-install, maintenance-free, stable in temperature and avoid stick-slip effect. Speeds from 0.47″”/min. (12 mm/min.) can be driven at a low thrust force using the adjustment screw on the base of the hydraulic control.
Hydraulic feed controls with the designations MA and MVC are especially used in handling modules or linear carriages and also for applications with changing usage data.
TECHNICAL DATA
|
Energy capacity 31 in-lbs/cycle Energy capacity 50,000 in-lbs/h Effective weight min. 0.5 lbs Effective weight max. 31 lbs Return Force min. 1.16 lbs Return Force max. 1.57 lbs Return Time 0.3 s Side Load Angle max. 2 ° Impact velocity range At speeds of 0.98 ft/sec the maximum allowed energy is approx. 17.70 in-lbs. Where higher energies occur use a shock absorber for the initial impact. Avoid high impact velocities. Operating temperature range 32 °F to 150 °F Mounting In any position Positive stop Integrated Adjustment Hard impact at the start of stroke, adjust the ring towards 9 or PLUS. Hard impact at the end of stroke, adjust the ring towards 0 or MINUS. Material Outer body, Accessories: Steel corrosion-resistant coating; Piston rod: Hardened stainless steel Damping medium Oil, temperature stable
NOTEIf precise end position data is required consider use of a stop collar. Shock absorber is preset at delivery in a neutral position between hard and soft. SAFETY INFORMATIONExternal materials in the surrounding area can attack the seal components and lead to a shorter service life. Please contact ACE for appropriate solution suggestions. Do not paint the shock absorbers due to heat emission. ON REQUESTNickel-plated or other special options available to special order. Models without rod end button. SALES DATAWeight F and R Weight S Weight Customs tariff number Country of origin |
