MA50M ACE Controls Miniature Shock Absorbers
$0.00
| Stroke | 0.28 inch |
| M | M10x1 inch |
Miniature Shock Absorbers
MA50M
Stepless adjustment
Adjustable
Energy capacity 50 in-lbs/cycle
Stroke 0.28 inch
There are also plenty of accessories for the MA and MVC models. All products are ready-to-install, maintenance-free, stable in temperature and avoid stick-slip effect. Speeds from 0.47″”/min. (12 mm/min.) can be driven at a low thrust force using the adjustment screw on the base of the hydraulic control.
These adjustable miniature shock absorbers from ACE can be used to precisely meet the customer’s application needs and are therefore found everywhere in industrial, automation and machine engineering and many other applications.
TECHNICAL DATA
|
Energy capacity 50 in-lbs/cycle Energy capacity 120,000 in-lbs/h Effective weight min. 10 lbs Effective weight max. 45 lbs Return Force min. 0.47 lbs Return Force max. 1.80 lbs Return Time 0.3 s Side Load Angle max. 2 ° Impact velocity range 2.4 ft/sec to 5.2 ft/sec Operating temperature range 32 °F to 150 °F Mounting In any position Positive stop Integrated Adjustment Hard impact at the start of stroke, adjust the ring towards 9 or PLUS. Hard impact at the end of stroke, adjust the ring towards 0 or MINUS. Material Outer body, Accessories: Steel corrosion-resistant coating; Piston rod: Hardened stainless steel Damping medium Oil, temperature stable
NOTEIf precise end position data is required consider use of a stop collar. Shock absorber is preset at delivery in a neutral position between hard and soft. SAFETY INFORMATIONExternal materials in the surrounding area can attack the seal components and lead to a shorter service life. Please contact ACE for appropriate solution suggestions. Do not paint the shock absorbers due to heat emission. ON REQUESTNickel-plated or other special options available to special order. Models without rod end button.
TECHNICAL DATA
|
