SALD11/8X4-P ACE Controls Industrial Shock Absorbers
$0.00
-P_U_GT_TECHdraw-SL-F_RGB-L_US.jpg)
| Stroke | 3.91 inch |
| A max. | 12.88 inch |
| L2 | 7.50 inch |
Industrial Shock Absorbers
SALD11/8X4-P
High energy absorption and a wide effective weight range
Adjustable
Energy capacity 32,000 in-lbs/cycle
Stroke 3.91 inch
High energy absorption and a wide damping range lead to huge advantages in practice. Alongside generally more compact designs, these small yet very powerful shock absorbers enable full use of the machine’s performance.
TECHNICAL DATA
|
Energy capacity 32,000 in-lbs/cycle Energy capacity 2,000,000 in-lbs/h Energy capacity with air/oil tank 4,000,000 in-lbs/h Effective weight min. 160 lbs Effective weight max. 100,000 lbs Impact velocity range 1 ft/sec to 15 ft/sec Operating temperature range 10 °F to 150 °F Mounting In any position Positive stop External Material Outer body: Nitride hardened steel; Piston rod: Hard chrome plated steel; Rod end button: Hardened steel and corrosion-resistant coating; Return spring: Zinc plated or plastic-coated steel Damping medium Automatic Transmission Fluid (ATF SAFETY INFORMATIONExternal materials in the surrounding area can attack the seal components and lead to a shorter service life. Please contact ACE for appropriate solution suggestions. Do not paint the shock absorbers due to heat emission.
SALES DATAWeight F and R Weight S Weight Country of origin Customs tariff number |
