SALD3/4X1-P ACE Controls Industrial Shock Absorbers
$0.00
| Stroke | 0.91 inch |
| A max. | 5.94 inch |
| L2 | 3.97 inch |
Industrial Shock Absorbers
SALD3/4X1-P
High energy absorption and a wide effective weight range
Adjustable
Energy capacity 3,000 in-lbs/cycle
Stroke 0.91 inch
High energy absorption and a wide damping range lead to huge advantages in practice. Alongside generally more compact designs, these small yet very powerful shock absorbers enable full use of the machine’s performance.
TECHNICAL DATA
|
Energy capacity 3,000 in-lbs/cycle Energy capacity 1,100,000 in-lbs/h Energy capacity with air/oil tank 1,600,000 in-lbs/h Effective weight min. 20 lbs Effective weight max. 18,000 lbs Impact velocity range 1 ft/sec to 15 ft/sec Operating temperature range 10 °F to 150 °F Mounting In any position Positive stop External Material Outer body: Nitride hardened steel; Piston rod: Hard chrome plated steel; Rod end button: Hardened steel and corrosion-resistant coating; Return spring: Zinc plated or plastic-coated steel Damping medium Automatic Transmission Fluid (ATF)
SAFETY INFORMATIONExternal materials in the surrounding area can attack the seal components and lead to a shorter service life. Please contact ACE for appropriate solution suggestions. Do not paint the shock absorbers due to heat emission.
SALES DATAWeight F and R Weight S Weight Country of origin Customs tariff number |
