SP1000-DP PNEUMATIC Shuttle Pro-1000 Drive Plate Includes: Guide Bearings & Retainers

SP1000-DP PNEUMATIC Shuttle Pro-1000 Drive Plate Includes: Guide Bearings & Retainers

SPECIFICATIONS:

• Part Number / SKU: SP1000-DP
• Product Name: Shuttle Pro-1000 Drive Plate Assembly
• Manufacturer: Pneumatic Innovations LLC
• Compatible Equipment: Shuttle Pro-1000 Pneumatic Conveyor Drive (Shaker Motor)
• Product Category: Specialized Spare Parts / Structural & Guide Assemblies
• Component Type: Integrated linear drive plate assembly featuring factory-installed guide bearings and bearing retainers.
• Function: Serves as the primary structural interface connecting the internal reciprocating pneumatic drive piston to the external conveyor tray, ensuring precise linear movement and load distribution.
• System Operating Environment: Engineered to maintain rigid alignment and support up to 1,000 lbs of push force under continuous operation of up to 120 strokes/minute at a maximum of 80 PSI.
• Application / Lifecycle: High-stress mechanical assembly. Replaced when guide bearings exhibit excessive lateral play or wear, protecting the internal drive shaft from bending or off-center forces.
