1606-XLS240E Allen Bradley POWER SUPPLY 24V,10A Single Phase Input

Technical Specifications

Electrical

Nominal value output voltage 1 24 V
Secondary voltage adjustable Yes
Max. output current 1 10 A
Nominal value output current 1 10 A
Power output 240 W
Voltage type of supply voltage AC
1st secondary output voltage 24 V
Rated supply voltage at AC 50 Hz 380 V
Rated supply voltage at AC 60 Hz 380 V
Power reserves 20 %
Input inrush current limiter Active
Power factor 0.53 typical
Output current range 10 to 8.6 A
External input fuse, min B-6 A or C-3 A
Power losses 18.6 W typical
Derating 6 W/°C
Efficiency 92.8 % typical
Input inrush current 4 A/4 A
Output voltage stabilized Yes
Rail mounting possible Yes
Stabilized Yes

Mechanical

Height 124 mm
Depth 117 mm
Direct mounting possible No
Width 62 mm
Degree of protection (IP) IP20
Type of electric connection Screw connection
MTBF 975 kh (+40 °C, SN29500)
Wall mounting possible Yes

Environmental

Ripple and noise, max 50 mV
Operating temperature -25 °C
Lifetime, min 54 kh (+40 °C)

Construction

Weight 750 g
