1746-OV16 Allen-Bradley Discrete output module
$0.00
1746-OV16 is an Allen-Bradley manufacture discrete output module. This module is provided with Sixteen (16) output channels in One (1) channel group. It is a sinking output module that delivers 10-50VDC output voltage range with minimum output of 24VDC. This module is ideally used to energize DC operated electrical loads such as relay coils, indicating and sounding devices.
The 1746-OV16 has a backplane current consumption of 0.270 Amperes at 5VDC with OFF-state leakage current of 1 mA and minimum load current of 1 mA as well. Each channel of this output module has a signal delay of 0.1 ms for ON to OFF transition and 1.0 ms for OFF to ON transition. The module’s continuous output current per point is 0.50 A at 30 °C (86 °F) and 0.25 A at 60 °C (140 °F) while the continuous output current per module is 8.0 A at 30 °C (86 °F) and 4.0 A at 60 °C (140 °F). This module exhibits a maximum On-state voltage drop 1.2V at 0.5 A.
The 1746-OV16 has a Surge current per point of 3.0 A for 10 ms that is repeatable once every 1 second 30 °C (86 °F) and 2 seconds repeatability at 60 °C (140 °F).
The 1746-OV16 is installed to an SLC 500 chassis. It is a single slot-width module that directly attached to a Modular style SLC 500 hardware. It comes with a removable terminal block that is pre-installed to the module. This terminal block may be removed from the module to implement easier and faster wiring activity.
It is a 16 channel output module that is compatible with the SLC 500 system. It has a heat dissipation per point of 0.388W and a total heat dissipation of 7.6W. The 1746-OV16 has a removable terminal block which allows you to connect or modify the wiring on the module easily. It has an operating voltage that ranges from 10-50V DC. It has a higher backplane current consumption (0.27 A) than the 1746-OV8 and the 1746-OVP16 modules. The 1746-OV16 has a maximum signal delay of 0.1ms in the On-state and of 1ms in the Off-state. It has a continuous current per output and per module of 0.5A and 8A at 30°C and 0.25A and 4A at 60°C, respectively. The 1746-OV16 has a maximum Off-state leakage of 1 mA and a maximum On-state voltage drop of 1.2V at 0.5A and 3A for 10ms maximum surge current per point.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Surge current per point | 3.0 A for 10 ms |
| On-state voltage drop, max | 1.2V at 0.5 A |
| Continuous current per module | 8.0 A at 30 °C (86 °F); 4.0 A at 60 °C (140 °F) |
| Continuous current per point | 0.50 A at 30 °C (86 °F); 0.25 A at 60 °C (140 °F |
| Signal delay, max. resistive load | On = 0.1 ms; Off = 1.0 ms |
| Backplane current consumption | 0.270 A |
| Wiring configuration | Sink wiring configuration |
| Input Voltage Range | 10-50 VDC |
| Nom Input Voltage | 24VDC |
| Part Number/Catalog No. | 1746-OV16 |
| Series | SLC 500 |
| Module Type | Discrete output module |
| Voltage Range | 10-50 Volts DC Sink |
| Outputs | 16 |
| Current/Output | 0.5 or 0.25 amps |
| Current/Module | 8 or 4 amps |
| Backplane Current (5 Volts) | 270 milliamps |
| Applications | General Purpose DC Outputs |
| Applications | High Current |
| Step Response | 60 milliseconds in, 2.5 milliseconds out |
Detalles
1746-OV8 Allen Bradley
Is a digital I/O module for the SLC 500 system. It is a current sinking 24V DC output module and it has applications in general use. The 1746-OV8 module has an operating voltage of 10-50V DC (sink) and 8 outputs with 8 point per common.
Features:
- Backplane current consumption of 135mA at 5V DC and 0mA at 24V DC.
- Maximum signal delay of 0.1ms in On-state and 1ms in Off-state.
- Continuous current per output and per module of 1A and 8A at 30°C and 0.5A and 4A at 60°C respectively.
- Maximum Off-state leakage of 1mA and a maximum thermal dissipation of 6.9W.
- Maximum On-state voltage drop of 1.2V at 1A and 3A for 10ms maximum surge current per point.
- Equipped with color-coded removable terminal blocks.
- For wiring, a pre-wired cable and a 1492 interface module can be used.
- Self-lifting pressure plates at the terminals that can accept up to two 14 AWG (2 mm2) wires.
- To display the I/O point status, it has LED indicators on the front panel.
- The 1746-OV8 is intended for use in a clean and dry industrial environment with a 0 – 60 °C operating temperature and a 30g operating shock.
Specifications:
- Manufacturer Rockwell Automation
- Brand Allen-Bradley
- Agency Certification UL / C-UL listed Class I, Division 2, Groups A, B, C, D CE marked for all applicable directives C-Tick
- marked for
- Relative Humidity 5 to 95% without condensation
- Operating Temperature 0…+60 °C (+32…+140 °F)
- Storage Temperature -40°C to +85°C (-40°F to +185°F)
- Continuous output current per module: 8.0 A @ 30 °C (86 °F); 4.0 A @ 60 °C (140 °F)
- Continuous output current per point 1.0 A @ 30 °C (86 °F); 0.50 A @ 60 °C (140 °F)
- Signal delay: ON = 0.1 ms; OFF = 1.0 ms
- Output voltage range: 10-50 VDC
- No. of groups: 1
- Part Number/Catalog No. 1746-OV8
- Series SLC 500
- Module Type 24VDC output module
- Voltage Range 10-50 Volts DC Sink
- Outputs 8
- Current/Output 1 or 0.5 amps
- Current/Module 8 or 4 amps
- Backplane Current (5 Volts) 135 milliamps
- Applications High-Density, Low-Current DC Outputs
- Applications High Current
- Step Response 60 milliseconds in, 2.5 milliseconds out
