1769-L33ER Allen Bradley Processor Module

1769-L33ER Allen Bradley Processor Module

Is a compact Logix controller. The 1769-L33ER can communicate with the controller or other devices through the Ethernet port. This controller has built-in user memory of 2 MB.  It is packaged with an optional non-volatile memory card which amounts to 1GB, thay may be expanded up to 2GB.

Features:

• Sixteen (16) I/O modules with a maximum of Three (3) I/O banks connected by appropriate expansion cables.
• Draw current of 5 Volts DC at 560 mA across 4 power supply modules and has a maximum power dissipation of 4.5 Watts.
• Has a 500 mA @ 5VDC backplane current draw and a maximum bus insulation 30 Volts.
• The 1769-L33ER can be mounted using either a DIN rail or panel mounting.

Specifications:

• Manufacturer Rockwell Automation / Allen-Bradley
• Brand Allen-Bradley
• Product Family: CompactLogix
• Part Number/Catalog No. 1769-L33ER
• Product Type: Programmable Automation Controller
• Product Line CompactLogix 5370
• Module Type Processor Module
• Communication ports: 1 USB; 1 Ethernet
• Communication Ethernet
• Supported Protocols: EtherNet I/P
• Memory 2MB
• Maximum number of I/O modules supported: 32 Modules
• Shipping Weight 2 pounds
• Maximum number of I/O banks supported: 3 banks
• No. of tasks: 32
• Series A and B
• Programs per task: 100
• Shipping Dimensions 8 x 8 x 5 inches
• Non-Volatile memory: 1784-SD1 card with 1 Gb of available memory (shipped with controller) ; 1784-SD2 card with 2 Gb of available memory (available for separate ordering)
• Wire Type Copper-90 degrees Celsius
• Battery: 1747-BA
• Wire Size (Solid) 22 to 14 AWG
• Vibration: Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak
• Wire Size (Stranded) 22 to 16 AWG
• Operating Temperature: 0° to +60°C (+32° to +140°F)
• Certifications: c-UL-us; CE; C-Tick; CI
• Battery requirement Not Necessary (Internal energy storage)
• Mounting DIN Rail; Panel Mounting
• Local Expansion Modules 16
• UPC 10885630101221
