1769-L35CR Allen Bradley Processor Module
Is a Logix controller . Devices can connect to the 1769-L35CR using 1756-CP3 and 1747-CP3 cables through an RS-232 port. The 1769-L35CR must be strategically placed within the 4 power supply modules.
Features:
- It can support up to 30 I/O modules connectable with 2 unique expansion cables to up to 3 I/O banks.
- 30-module expansion capacity.
- Has a (5V) DC draw current of 680mA
- Heat dissipation of up to 4.36W.
- Maximum wire insulation of 30V
- Backplane current of 680mA (5V DC).
- Can be mounted easily with a DIN rail mount
- 20G operational shock rating or on a panel mount at the same shock rate.
Specifications:
- Manufacturer Rockwell Automation
- Brand Allen-Bradley
- Part Number/Catalog No. 1769-L35CR
- Product Line CompactLogix
- Module Type Processor Module
- Communication Serial
- Memory 1.5MB
- Shipping Weight 2 lbs.
- Shipping Dimensions 8X8X5 in.
- Series A and B
- Wire Type Copper-90 degrees Celsius
- Wire Size (Solid) 22-14 AWG
- Wire Size (Stranded) 22-16 AWG
- UNSPSC 32151705
- Product Lifecycle Status* Discontinued/Obsolete
