Electrical features
Service voltage
10 … 35 V DC (Supply Class 2)
No-load current (max.)
11 mA
Insulation voltage endurance
1000 V
Mechanical features
Internal diameter
20,1 mm
Housing material
Plastic (PA)
Certifications, approvals
Protection class
III, operation on protective low voltage
General features
Operating principle
inductive
Output, input, interface
Switching output
npn, 200 mA, NO
Detection range, measuring range, tolerance limits
Display, operation
Sensitivity adjustment
no setting elements
Time behavior
Speed of parts (max.)
35 m/s
Readiness delay (max.)
300 ms
Ambient conditions
Shock/vibration load
30 g, 11 ms / 10 … 55 Hz, 1.0 mm
Ambient temperature during operation
-25 … +70 °C
Electrical connection
Connection
Connector, M12, 4-pin
