RD 9 XMF Tesla Electron Tube Triodo ITL9-1
$0.00
The RD 9 XMF is a high – amplification, water cooled power triode, manufactured in metal – ceramic technology, suitable for industrial generators and amplifiers up to 120 MHz and up to 25 kW.
RD9XMF is air-cooled triode, made by metal-ceramic technology. This electron tube is intended for industrial generators up to 120 MHz. Application – RF heating, welding, hardening or gluing. Maximum plate dissipation can be 8.5 kW. Output power is 25 kW in CW mode. For operation in pulse mode, the parameters depends on equipment characteristics. Contact us for specific information.
Technical specifications
Cathode WTh
Filament voltage 5.8 V
Filament current 145 A
Amplification factor 22
Transconductance 50 mA/V
Capacitance
• grid-anode 21 PF
• grid-cathode 55 PF
• cathode-anode 1 PF
Frequency 120 MHz
Anode voltage
• <30 MHz 12 kV
• 2 30 MHz 9-7 kV
Grid voltage -1500 V
Grid current 1.5 A
Grid dissipation 350 w
Anode dissipation 8.5 kW
Peak cathode current 25 A
Additional accessories*
Mechanical characteristics and cooling
Anode cooling air
Air inlet temperature 45 oC
Temperature (any point of envelope) 200 °C
Air outlet temperature 75 °C
Air flow 9.5 m3/min
Mounting position vertical
Weight 4.4 kg
• Grid contact ring
*for detailed information please contact our sales department
