U300.P50-GP2J.72N Baumer Ultrasonic proximity sensors 11219504
$0.00
Ultrasonic 2 point proximity switch
General data
- Special type
-
- 2 point proximity switch
- Scanning range Sd
-
- 15 … 500 mm
- Scanning range far limit Sde
-
- 15 … 500 mm
- Version
-
- IO-Link dual channel
- Multiplex version
- Hysteresis typ.
-
- 4 % Sde
- Repeat accuracy
-
- 0.5 mm
- Temperature drift
-
- < 2 % Sde
- Power-up drift
-
- Compensated after 15 min.
- Response time ton/toff min
-
- < 16 ms
- Response time ton/toff standard
-
- < 40 ms
- Sonic frequency
-
- 290 kHz
- Adjustment
-
- qTeach, line-Teach, IO-Link
- Output indicator
-
- Yellow LED / red LED
- Power on indication
-
- LED green
- Alignment measuring axis
-
- < 2°
Electrical data
- Voltage supply range +Vs
-
- 12 … 30 VDC
- Current consumption typ.
-
- 35 mA
- Output circuit
-
- Push-pull
- Output current
-
- 100 mA
- Voltage drop Vd
-
- <3 VDC
- Residual ripple
-
- < 10 % Vs
- Short circuit protection
-
- Yes
- Reverse polarity protection
-
- Yes
Communication interface
- Interface
-
- IO-Link V1.1
- Baud rate
-
- 38,4 kBaud (COM 2)
- Cycle time
-
- ≥ 8 ms
- Process data length
-
- 48 Bit
- Process data structure
-
- Bit 0 = SSC1 (distance)
- Bit 1 = SSC2 (distance)
- Bit 2 = quality
- Bit 3 = alarm
- Bit 5 = SSC4 (counter)
- Bit 8-15 = scale factor
- Bit 16-47 = 32 Bit measurement
- IO-Link port type
-
- Class A
- Additional data
-
- Distance
- Excess gain
- Operating cycles
- Operating hours
- Boot cycles
- Operating voltage
- Device temperature
- Histograms
- Adjustable parameters
-
- Time filters
- LED status indicators
- Output logic
- Output circuit
- Counter
- Beam forming
- Deactivate the sensor element
- Find Me function
- IO-Link
-
- Yes
Mechanical data
- Design
-
- Rectangular
- Housing material
-
- Plastic (ASA, PMMA)
- Width / diameter
-
- 12.9 mm
- Height / length
-
- 32.2 mm
- Depth
-
- 23 mm
- Connection types
-
- Connector M8 4 pin
Ambient conditions
- Operating temperature
-
- -25 … +65 °C
- Storage temperature
-
- -40 … +75 °C
- Protection class
-
- IP 67
