156996 NORDSON FILTER, 36, POWDERGRID PLUS, CENTER-MT

156996 NORDSON FILTER, 36, POWDERGRID PLUS, CENTER-MT

FEATURES:


• Shape Round folded filter cartridge with 2 metal bands
• Top / Bottom Top open, bottom closed with a 0.41″ bolt hole
• Filter Media Can be made of fiberglass (glass fiber), metal mesh, filter paper, PP, sintered felt, sintered mesh, powder sintered, or polypropylene
• Filtration Efficiency Up to 99.9% with PTFE membrane treatment technology used in some aftermarket versions (aftermarket)
• Material Construction Folded pleat design; aftermarket versions may use TORAY filter material as the base fabric with PTFE membrane treatment on the surface for enhanced performance
• Applications Powder coating recovery systems in spray booths; dust removal in industries including steel, automotive, electronics, chemical, pharmaceuticals, food, mining, power plants, and shipbuilding

SPECIFICATIONS:


• Model Name/Number 156996
• Length 36.00″ (approx. 914 mm)
• Dimensions (Product) 8.375 x 12.75 x 36 inches (approx. 21.3 cm x 32.4 cm x 91.4 cm)
• Shape / Form Factor Round with 2 metal bands
• Top / Bottom Configuration Top open, bottom closed with a 0.41″ bolt hole
• Filtration Accuracy (Range) 0.01 – 500 μm
• Operating Temperature -30°C to 115°C (can be extended to 120°C in some configurations)
• Maximum Working Pressure Up to 420 kg (approx. 450 kg in some configurations)
• Maximum Differential Pressure 0.2 MPa
• Media / Filter Element Material Fiberglass, metal mesh, filter paper, PP, sintered felt, sintered mesh, powder sintered, polypropylene
