PD10 S-ASS-STT ARO METALLIC PUMP 52.2 GPM (196.6 LPM)

ARO PD10S-ASS-STT 1″ Metallic Expert Series AODD Diaphragm Pump.

• Stainless Steel Center Body
• Stainless Steel Fluid Caps & Manifold
• Stainless Steel Hardware. 52.2 GPM (197.6 LPM) Maximum Flow Rate
• 316 Stainless Steel Seats
• PTFE Balls
• PTFE / Santoprene Diaphragm
• 1 – 11-1/2 NPTF – 2 Connection

Specifications:

• Air Inlet:  1/4 – 18 NPT
• CCN Number: 15202567
• Connection Size: 1″
• Connection Type: 1 – 11-1/2 NPTF – 2
• Diaphragm: PTFE / Santoprene
• Discharge Volume Per Cycle: 0.232 Gal (0.88 Lit)
• Inlet Pressure (PSI): 120 psig (8.3 bar)
• Liquid End Configuration: Stainless Steel Fluid Caps & Manifold
• Material: Stainless Steel Center Body
• Maximum Flow (GPM): 52.2 GPM (197.6 LPM)
• Maximum Working Pressure (PSIG): 120 psi (8.3 bar)
• Max Suction Lift: 19 Feet (5.7m)
• ​Metal Parts Stainless Steel Hardware
• Model Series: 1” Metallic Expert Series
• Quick Specs: 1 IN EXP METALLIC DIAPH PUMP PD10S-ASS-STT
• Solids (Inches): 1/8″ (3.2mm)
• Temperature Range: 40° to 225° F (4° to 107° C)}
• Type: Standard Pump
• Valve Balls: PTFE
• Valve / Seat / O-Ring: 316 Stainless Steel
